Sunday, July 18, 2010

water pump and timing belt removal procedure for 1995 eagle telon

click the link

You have to get the timing belt off to get to the water pump..
So here are instructions for the timing belt.
And here is the water pump.

check out.

Monday, July 12, 2010

antifreeze leak


check fig:--

Sunday, July 11, 2010

power door lock e 350 ford.


check fig:--

Saturday, July 10, 2010

a refrigerator pump


check fig:--

Friday, July 9, 2010

1996 Saturn SC1 spark plug connections?

Saturn Spark Plug Firing Order:


Saturn timing specifications, the internal firing order for the Saturn 1.9L motor, both Single overhead cam, or Twin cam is as follows:
Left to right 1-3-4-2

For routing spark plug wires, the order of wires from the coils to the engine, is as follows:
Left to right 4-1-2-3

The plugs are numbered left to right as you look at the engine 1,2,3,4. The coil towers are numbered from your left to right as you look at them 4,1,2,3.
Connect the wire correctly from 1 to 1.
Also for help  there is a label on the radiator support with a diagram on it that shows this also. You should have a spark plug wire clip or 2 and the #4 and #1 wires must run next to each other from the coil to the head area.

Check Spark Plug Diagram Shown Below:

1996 Spark Plug Connection Diagram















Spark plug gap settings:

Saturn dealers, and Saturn themselves, all recommend the 0.060 inch (1.5 mm) specified gap should be 0.040 inch (1.0 mm) to avoid performance and driveability problems.

NOTE: Saturn recommends the original spark plugs should not be re-gapped — new spark plugs (P/N 21024004 - SOHC engine, or P/N 21024005 - DOHC engine) should be installed with gaps set to 0.40 inch (1.0mm).


Problems Related To Spark plug Gap:
If spark plug gaps on a Saturn (or any engine) are too large, performance and driveability problems, including hard starting, an engine miss and/or hesitation under load, will occur and appear similar to problems caused by badly worn high-mileage spark plugs.

Wednesday, July 7, 2010

porsche


check fig

porsche


check fig

2000 PORSCHE BOXTER, 5 SPEED TRANSMISSION.


check fig

Saturday, July 3, 2010

2001 Lexus ES 300 power mirror fuse and wiring diagram.

Lexus Power Mirror Not Working



There are two fuses. One in the main fuse box located in the engine compartment, and another fuse box behind the coin holder inside the car. You will need to pop-out the coin holder to access that fuse box.

Its a 10A Fuse. There should be only 2 10A fuses there. It also controls the Driver's side memory seat, and the AC, SRS, and some other circuits.

Check Fig Below:

There should be a diagram under the hood

Dashboard Fuse Box Location For Lexus 300



under hood engine compartment fuse box for lexus 300




Problem Solved:
To Know How the problem Solved Click here






Lexus es300 sideview mirrors schematics


check fig:--

@
